Portable R1234yf / R134a Refrigerant Analyzer with Printer – REFPRO 5.0

The REFPRO 5.0 is a modern, portable refrigerant analyzer equipped with an integrated thermal printer. It uses advanced non-dispersive infrared (NDIR) technology to deliver fast and highly accurate refrigerant analysis.

The device is designed for precise identification of R1234yf and R134a refrigerants. It also detects contaminants such as:

• hydrocarbons (HC)
• moisture
• air

Additionally, the analyzer identifies dangerous and illegal substitute refrigerants and mixtures, including propane and butane, significantly improving workshop safety.

Key Features

• Fast and precise refrigerant analysis
• Displays percentage composition of gases (R1234yf, R134a, HC, air)
• Clear indication of refrigerant type
• Increased resistance to oil contamination (replaceable oil trap)
• Integrated calibration pump
• Built-in thermal printer for instant result documentation

Kit Includes

• Carrying case
• Power cable
• R134a connector
• R1234yf connector
• Quick coupling for easy gas connector exchange
• User manual

Technical Data

• Display: 4.3" color touchscreen
• Power supply: 230V / 12V, 50/60 Hz
• Printer: built-in thermal printer
• Purge chamber: internal
• Communication: USB 2.0
• User interface: LCD + 3 buttons
• Certifications: CE, SAE

Measurement Specifications

• Tested refrigerants: R1234yf, R134a
• Accuracy: better than ±1.0%
• Displayed values: percentage concentration of R1234yf, R134a, HC, and air
• Operating temperature range: 10°C to 50°C
• Oil contamination handling: replaceable oil trap
